Technical data

Newbourne 60 Convector Inset

Nominal output

7W

Range rating

6-9KW

Flue outlet diameter

Ø125 mm top

Heating area

10-100 m2

Weight

110 kg

Distance to flammable materials

to furniture

90cm

Width of wood chamber

30cm

Max log length

29cm

Dimension of convection box in mm

529 x 406 x  340mm (HxWxD)

Dimension of front exposed part of stove

606 x 545 x 128mm (HxWxD)

Distance of centre of top flue outlet from rear of stove front

257mm

Colour options

Black

Efficiency when burning wood

78%

Efficiency when burning solid fuel

79%

For brochure download click here

2013 Brochure on the Newbourne 60 Convector Inset Defra approved range

Can be installed on a 12mm hearth

CE mark, EN13229, Defra approved for smoke control zones
